FeRAM Product List
Below is a list of FeRAM products offered by RAMXEED. In this list, you can reorder and filter products by specifications, interface, and grade. Click the button next to a product's part number to download a datasheet and check supported simulation models or buy via online shopping.
|
Part number
|
Product model
|
Grade
|
I/F
|
Memory
density |
Power Supply Voltage
(min.) |
Power Supply Voltage
(max.) |
Operating Freq.
|
Cycle
time |
Operating temp.
|
Read/Write Cycle
|
Package
|
Packaging
|
Availability
|
||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| MB85RQ8MX | Datasheet | Verilog | IBIS | Buy | MB85RQ8MXPF-G-BCE1 | Industrial Grade | Quad SPI | 8Mbit | 2.7V | 3.6V | 108MHz | ― | -40～+105℃ |
1014cycles |
SOP-16 | Tray | In mass production |
| Buy | MB85RQ8MXPF-G-BCERE1 | Industrial Grade | Quad SPI | 8Mbit | 2.7V | 3.6V | 108MHz | ― | -40～+105℃ |
1014cycles |
SOP-16 | Embossed taping | In mass production | ||||
| MB85RQ8MLX | Datasheet | Verilog | IBIS | Buy | MB85RQ8MLXPF-G-BCE1 | Industrial Grade | Quad SPI | 8Mbit | 1.7V | 1.95V | 108MHz | ― | -40～+105℃ |
1014cycles |
SOP-16 | Tray | In mass production |
| Buy | MB85RQ8MLXPF-G-BCERE1 | Industrial Grade | Quad SPI | 8Mbit | 1.7V | 1.95V | 108MHz | ― | -40～+105℃ |
1014cycles |
SOP-16 | Embossed taping | In mass production | ||||
| MB85RS4MTY | Datasheet | Verilog | IBIS | Buy | MB85RS4MTYPN-GS-AWEWE1 | Automotive Grade AEC-Q100 compliant | SPI | 4Mbit | 1.8V | 3.6V | 50MHz | ― | -40～+125℃ |
1013cycles |
DFN-8 (5mmx6mm) | Embossed taping | In mass production |
| Buy | MB85RS4MTYPN-G-AWEWE1 | Industrial Grade | SPI | 4Mbit | 1.8V | 3.6V | 50MHz | ― | -40～+125℃ |
1013cycles |
DFN-8 (5mmx6mm) | Embossed taping | In mass production | ||||
| Buy | MB85RS4MTYPF-G-BCE1 | Industrial Grade | SPI | 4Mbit | 1.8V | 3.6V | 50MHz | ― | -40～+125℃ |
1013cycles |
SOP-8 (208mil) | Tube | In mass production | ||||
| Buy | MB85RS4MTYPF-G-BCERE1 | Industrial Grade | SPI | 4Mbit | 1.8V | 3.6V | 50MHz | ― | -40～+125℃ |
1013cycles |
SOP-8 (208mil) | Embossed taping | In mass production | ||||
| MB85RS4MLY | Datasheet | Verilog | IBIS | Buy | MB85RS4MLYPN-GS-AWEWE1 | Automotive Grade AEC-Q100 compliant | SPI | 4Mbit | 1.7V | 1.95V | 50MHz | ― | -40～+125℃ |
1013cycles |
DFN-8 (5mmx6mm) | Embossed taping | In mass production |
| Buy | MB85RS4MLYPN-G-AWEWE1 | Industrial Grade | SPI | 4Mbit | 1.7V | 1.95V | 50MHz | ― | -40～+125℃ |
1013cycles |
DFN-8 (5mmx6mm) | Embossed taping | In mass production | ||||
| Buy | MB85RS4MLYPF-G-BCE1 | Industrial Grade | SPI | 4Mbit | 1.7V | 1.95V | 50MHz | ― | -40～+125℃ |
1013cycles |
SOP-8 (208mil) | Tube | In mass production | ||||
| Buy | MB85RS4MLYPF-G-BCERE1 | Industrial Grade | SPI | 4Mbit | 1.7V | 1.95V | 50MHz | ― | -40～+125℃ |
1013cycles |
SOP-8 (208mil) | Embossed taping | In mass production | ||||
| MB85RS4MT | Datasheet | Verilog | IBIS | Buy | MB85RS4MTPF-G-BCE1 | Industrial Grade | SPI | 4Mbit | 1.8V | 3.6V | 40MHz | ― | -40～+85℃ |
1013cycles |
SOP-8 (208mil) | Tube | In mass production |
| Buy | MB85RS4MTPF-G-BCERE1 | Industrial Grade | SPI | 4Mbit | 1.8V | 3.6V | 40MHz | ― | -40～+85℃ |
1013cycles |
SOP-8 (208mil) | Embossed taping | In mass production | ||||
| MB85RQ4ML | Datasheet | Verilog | IBIS | Buy | MB85RQ4MLPF-G-BCE1 | Industrial Grade | SPI | 4Mbit | 1.7V | 1.95V | 108MHz | ― | -40～+85℃ |
1013cycles |
SOP-16 | Tray | In mass production |
| Buy | MB85RQ4MLPF-G-BCERE1 | Industrial Grade | SPI | 4Mbit | 1.7V | 1.95V | 108MHz | ― | -40～+85℃ |
1013cycles |
SOP-16 | Embossed taping | In mass production | ||||
| MB85RS2MTY | Datasheet | Verilog | IBIS | Buy | MB85RS2MTYPN-GS-AWEWE1 | Automotive Grade AEC-Q100 compliant | SPI | 2Mbit | 1.8V | 3.6V | 50MHz | ― | -40～+125℃ |
1013cycles |
DFN-8 (5mmx6mm) | Embossed taping | In mass production |
| Buy | MB85RS2MTYPN-G-AWEWE1 | Industrial Grade | SPI | 2Mbit | 1.8V | 3.6V | 50MHz | ― | -40～+125℃ |
1013cycles |
DFN-8 (5mmx6mm) | Embossed taping | In mass production | ||||
| Buy | MB85RS2MTYPNF-GS-AWE2 | Automotive Grade AEC-Q100 compliant | SPI | 2Mbit | 1.8V | 3.6V | 50MHz | ― | -40～+125℃ |
1013cycles |
SOP-8 (150mil) | Tube | In mass production | ||||
| Buy | MB85RS2MTYPNF-GS-AWERE2 | Automotive Grade AEC-Q100 compliant | SPI | 2Mbit | 1.8V | 3.6V | 50MHz | ― | -40～+125℃ |
1013cycles |
SOP-8 (150mil) | Embossed taping | In mass production | ||||
| Buy | MB85RS2MTYPNF-G-AWE2 | Industrial Grade | SPI | 2Mbit | 1.8V | 3.6V | 50MHz | ― | -40～+125℃ |
1013cycles |
SOP-8 (150mil) | Tube | In mass production | ||||
| Buy | MB85RS2MTYPNF-G-AWERE2 | Industrial Grade | SPI | 2Mbit | 1.8V | 3.6V | 50MHz | ― | -40～+125℃ |
1013cycles |
SOP-8 (150mil) | Embossed taping | In mass production | ||||
| MB85RS2MLY | Datasheet | Verilog | IBIS | Buy | MB85RS2MLYPN-GS-AWEWE1 | Automotive Grade AEC-Q100 compliant | SPI | 2Mbit | 1.7V | 1.95V | 50MHz | ― | -40～+125℃ |
1013cycles |
DFN-8 (5mmx6mm) | Embossed taping | In mass production |
| Buy | MB85RS2MLYPN-G-AWEWE1 | Industrial Grade | SPI | 2Mbit | 1.7V | 1.95V | 50MHz | ― | -40～+125℃ |
1013cycles |
DFN-8 (5mmx6mm) | Embossed taping | In mass production | ||||
| Buy | MB85RS2MLYPNF-GS-AWE2 | Automotive Grade AEC-Q100 compliant | SPI | 2Mbit | 1.7V | 1.95V | 50MHz | ― | -40～+125℃ |
1013cycles |
SOP-8 (150mil) | Tube | In mass production | ||||
| Buy | MB85RS2MLYPNF-GS-AWERE2 | Automotive Grade AEC-Q100 compliant | SPI | 2Mbit | 1.7V | 1.95V | 50MHz | ― | -40～+125℃ |
1013cycles |
SOP-8 (150mil) | Embossed taping | In mass production | ||||
| Buy | MB85RS2MLYPNF-G-AWE2 | Industrial Grade | SPI | 2Mbit | 1.7V | 1.95V | 50MHz | ― | -40～+125℃ |
1013cycles |
SOP-8 (150mil) | Tube | In mass production | ||||
| Buy | MB85RS2MLYPNF-G-AWERE2 | Industrial Grade | SPI | 2Mbit | 1.7V | 1.95V | 50MHz | ― | -40～+125℃ |
1013cycles |
SOP-8 (150mil) | Embossed taping | In mass production | ||||
| MB85RS2MTA | Datasheet | Verilog | IBIS | Buy | MB85RS2MTAPF-G-BCE1 | Industrial Grade | SPI | 2Mbit | 1.7V | 3.6V | 40MHz | ― | -40～+85℃ |
1013cycles |
SOP-8 (208mil) | Tube | In mass production |
| Buy | MB85RS2MTAPF-G-BCERE1 | Industrial Grade | SPI | 2Mbit | 1.7V | 3.6V | 40MHz | ― | -40～+85℃ |
1013cycles |
SOP-8 (208mil) | Embossed taping | In mass production | ||||
| Buy | MB85RS2MTAPNF-G-BDE1 | Industrial Grade | SPI | 2Mbit | 1.7V | 3.6V | 40MHz | ― | -40～+85℃ |
1013cycles |
SOP-8 (150mil) | Tube | In mass production | ||||
| Buy | MB85RS2MTAPNF-G-BDERE1 | Industrial Grade | SPI | 2Mbit | 1.7V | 3.6V | 40MHz | ― | -40～+85℃ |
1013cycles |
SOP-8 (150mil) | Embossed taping | In mass production | ||||
| Buy | MB85RS2MTAPNF-G-AWE2 | Industrial Grade | SPI | 2Mbit | 1.7V | 3.6V | 40MHz | ― | -40～+85℃ |
1013cycles |
SOP-8 (150mil) | Tube | In mass production | ||||
| Buy | MB85RS2MTAPNF-G-AWERE2 | Industrial Grade | SPI | 2Mbit | 1.7V | 3.6V | 40MHz | ― | -40～+85℃ |
1013cycles |
SOP-8 (150mil) | Embossed taping | In mass production | ||||
| MS85RS1MTY | Datasheet | MS85RS1MTYPN-GS-AWE1 | Automotive Grade AEC-Q100 compliant | SPI | 1Mbit | 1.8V | 3.6V | 50MHz | ― | -40～+125℃ |
1013cycles |
DFN-8 (5mmx6mm) | Tray | ES available | |||
| MS85RS1MTYPN-GS-AWEWE1 | Automotive Grade AEC-Q100 compliant | SPI | 1Mbit | 1.8V | 3.6V | 50MHz | ― | -40～+125℃ |
1013cycles |
DFN-8 (5mmx6mm) | Embossed taping | ES available | |||||
| MS85RS1MTYPNF-GS-BDE1 | Automotive Grade AEC-Q100 compliant | SPI | 1Mbit | 1.8V | 3.6V | 50MHz | ― | -40～+125℃ |
1013cycles |
SOP-8 (150mil) | Tube | ES CY2025 | |||||
| MS85RS1MTYPNF-GS-BDERE1 | Automotive Grade AEC-Q100 compliant | SPI | 1Mbit | 1.8V | 3.6V | 50MHz | ― | -40～+125℃ |
1013cycles |
SOP-8 (150mil) | Embossed taping | ES CY2025 | |||||
| MS85RS1MTYPN-G-AWE1 | Industrial Grade | SPI | 1Mbit | 1.8V | 3.6V | 50MHz | ― | -40～+125℃ |
1014cycles |
DFN-8 (5mmx6mm) | Tray | ES available | |||||
| MS85RS1MTYPN-G-AWEWE1 | Industrial Grade | SPI | 1Mbit | 1.8V | 3.6V | 50MHz | ― | -40～+125℃ |
1014cycles |
DFN-8 (5mmx6mm) | Embossed taping | ES available | |||||
| MS85RS1MTYPNF-G-BDE1 | Industrial Grade | SPI | 1Mbit | 1.8V | 3.6V | 50MHz | ― | -40～+125℃ |
1014cycles |
SOP-8 (150mil) | Tube | ES CY2025 | |||||
| MS85RS1MTYPNF-G-BDERE1 | Industrial Grade | SPI | 1Mbit | 1.8V | 3.6V | 50MHz | ― | -40～+125℃ |
1014cycles |
SOP-8 (150mil) | Embossed taping | ES CY2025 | |||||
| MB85RS1MT | Datasheet | Verilog | IBIS | Buy | MB85RS1MTPNF-G-JNE1 | Industrial Grade | SPI | 1Mbit | 1.8V | 3.6V | 30MHz | ― | -40～+85℃ |
1013cycles |
SOP-8 (150mil) | Tube | In mass production |
| Buy | MB85RS1MTPNF-G-JNERE1 | Industrial Grade | SPI | 1Mbit | 1.8V | 3.6V | 30MHz | ― | -40～+85℃ |
1013cycles |
SOP-8 (150mil) | Embossed taping | In mass production | ||||
| Buy | MB85RS1MTPNF-G-AWE2 | Industrial Grade | SPI | 1Mbit | 1.8V | 3.6V | 30MHz | ― | -40～+85℃ |
1013cycles |
SOP-8 (150mil) | Tube | In mass production | ||||
| Buy | MB85RS1MTPNF-G-AWERE2 | Industrial Grade | SPI | 1Mbit | 1.8V | 3.6V | 30MHz | ― | -40～+85℃ |
1013cycles |
SOP-8 (150mil) | Embossed taping | In mass production | ||||
| Buy | MB85RS1MTPW-G-APEWE1 | Industrial Grade | SPI | 1Mbit | 1.7V | 3.6V | 30MHz | ― | -40～+85℃ |
1013cycles |
WL-CSP | Embossed taping | In mass production | ||||
| Buy | MB85RS1MTPN-G-AWEWE1 | Industrial Grade | SPI | 1Mbit | 1.8V | 3.6V | 30MHz | ― | -40～+85℃ |
1013cycles |
DFN-8 (5mmx6mm) | Embossed taping | In mass production | ||||
| Buy | MB85RS1MTPNF-G-AME2 | Industrial Grade | SPI | 1Mbit | 1.8V | 3.6V | 30MHz | ― | -40～+85℃ |
1013cycles |
SOP-8 (150mil) | Tray | In mass production | ||||
| Buy | MB85RS1MTPNF-G-AMERE2 | Industrial Grade | SPI | 1Mbit | 1.8V | 3.6V | 30MHz | ― | -40～+85℃ |
1013cycles |
SOP-8 (150mil) | Embossed taping | In mass production | ||||
| MB85RS512TY | Datasheet | IBIS | Buy | MB85RS512TYPNF-GS-BCE1 | Automotive Grade AEC-Q100 compliant | SPI | 512Kbit | 1.8V | 3.6V | 50MHz | ― | -40～+125℃ |
1013cycles |
SOP-8 (150mil) | Tube | ES available | |
| Buy | MB85RS512TYPNF-GS-BCERE1 | Automotive Grade AEC-Q100 compliant | SPI | 512Kbit | 1.8V | 3.6V | 50MHz | ― | -40～+125℃ |
1013cycles |
SOP-8 (150mil) | Embossed taping | ES available | ||||
| Buy | MB85RS512TYPN-GS-AWE1 | Automotive Grade AEC-Q100 compliant | SPI | 512Kbit | 1.8V | 3.6V | 50MHz | ― | -40～+125℃ |
1013cycles |
DFN-8 (5mmx6mm) | Tray | ES available | ||||
| Buy | MB85RS512TYPN-GS-AWEWE1 | Automotive Grade AEC-Q100 compliant | SPI | 512Kbit | 1.8V | 3.6V | 50MHz | ― | -40～+125℃ |
1013cycles |
DFN-8 (5mmx6mm) | Embossed taping | ES available | ||||
| Buy | MB85RS512TYPNF-G-BCE1 | Industrial Grade | SPI | 512Kbit | 1.8V | 3.6V | 50MHz | ― | -40～+125℃ |
1013cycles |
SOP-8 (150mil) | Tube | ES available | ||||
| Buy | MB85RS512TYPNF-G-BCERE1 | Industrial Grade | SPI | 512Kbit | 1.8V | 3.6V | 50MHz | ― | -40～+125℃ |
1013cycles |
SOP-8 (150mil) | Embossed taping | ES available | ||||
| Buy | MB85RS512TYPN-G-AWE1 | Industrial Grade | SPI | 512Kbit | 1.8V | 3.6V | 50MHz | ― | -40～+125℃ |
1013cycles |
DFN-8 (5mmx6mm) | Tray | ES available | ||||
| Buy | MB85RS512TYPN-G-AWEWE1 | Industrial Grade | SPI | 512Kbit | 1.8V | 3.6V | 50MHz | ― | -40～+125℃ |
1013cycles |
DFN-8 (5mmx6mm) | Embossed taping | ES available | ||||
| MB85RS512LY | Datasheet | IBIS | Buy | MB85RS512LYPNF-GS-BCE1 | Automotive Grade AEC-Q100 compliant | SPI | 512Kbit | 1.7V | 1.95V | 50MHz | ― | -40～+125℃ |
1013cycles |
SOP-8 (150mil) | Tube | ES available | |
| Buy | MB85RS512LYPNF-GS-BCERE1 | Automotive Grade AEC-Q100 compliant | SPI | 512Kbit | 1.7V | 1.95V | 50MHz | ― | -40～+125℃ |
1013cycles |
SOP-8 (150mil) | Embossed taping | ES available | ||||
| Buy | MB85RS512LYPN-GS-AWE1 | Automotive Grade AEC-Q100 compliant | SPI | 512Kbit | 1.7V | 1.95V | 50MHz | ― | -40～+125℃ |
1013cycles |
DFN-8 (5mmx6mm) | Tray | ES available | ||||
| Buy | MB85RS512LYPN-GS-AWEWE1 | Automotive Grade AEC-Q100 compliant | SPI | 512Kbit | 1.7V | 1.95V | 50MHz | ― | -40～+125℃ |
1013cycles |
DFN-8 (5mmx6mm) | Embossed taping | ES available | ||||
| Buy | MB85RS512LYPNF-G-BCE1 | Industrial Grade | SPI | 512Kbit | 1.7V | 1.95V | 50MHz | ― | -40～+125℃ |
1013cycles |
SOP-8 (150mil) | Tube | ES available | ||||
| Buy | MB85RS512LYPNF-G-BCERE1 | Industrial Grade | SPI | 512Kbit | 1.7V | 1.95V | 50MHz | ― | -40～+125℃ |
1013cycles |
SOP-8 (150mil) | Embossed taping | ES available | ||||
| Buy | MB85RS512LYPN-G-AWE1 | Industrial Grade | SPI | 512Kbit | 1.7V | 1.95V | 50MHz | ― | -40～+125℃ |
1013cycles |
DFN-8 (5mmx6mm) | Tray | ES available | ||||
| Buy | MB85RS512LYPN-G-AWEWE1 | Industrial Grade | SPI | 512Kbit | 1.7V | 1.95V | 50MHz | ― | -40～+125℃ |
1013cycles |
DFN-8 (5mmx6mm) | Embossed taping | ES available | ||||
| MB85RS512T | Datasheet | Verilog | IBIS | Buy | MB85RS512TPNF-G-JNE1 | Industrial Grade | SPI | 512Kbit | 1.8V | 3.6V | 30MHz | ― | -40～+85℃ |
1013cycles |
SOP-8 (150mil) | Tube | NRND |
| Buy | MB85RS512TPNF-G-JNERE1 | Industrial Grade | SPI | 512Kbit | 1.8V | 3.6V | 30MHz | ― | -40～+85℃ |
1013cycles |
SOP-8 (150mil) | Embossed taping | NRND | ||||
| Buy | MB85RS512TPNF-G-AWE2 | Industrial Grade | SPI | 512Kbit | 1.8V | 3.6V | 30MHz | ― | -40～+85℃ |
1013cycles |
SOP-8 (150mil) | Tube | In mass production | ||||
| Buy | MB85RS512TPNF-G-AWERE2 | Industrial Grade | SPI | 512Kbit | 1.8V | 3.6V | 30MHz | ― | -40～+85℃ |
1013cycles |
SOP-8 (150mil) | Embossed taping | In mass production | ||||
| Buy | MB85RS512TPNF-G-AME2 | Industrial Grade | SPI | 512Kbit | 1.8V | 3.6V | 30MHz | ― | -40～+85℃ |
1013cycles |
SOP-8 (150mil) | Tray | In mass production | ||||
| Buy | MB85RS512TPNF-G-AMERE2 | Industrial Grade | SPI | 512Kbit | 1.8V | 3.6V | 30MHz | ― | -40～+85℃ |
1013cycles |
SOP-8 (150mil) | Embossed taping | In mass production | ||||
| MB85RS256TYA | Datasheet | IBIS | Buy | MB85RS256TYAPNF-GS-BCE1 | Automotive Grade AEC-Q100 compliant | SPI | 256Kbit | 1.8V | 3.6V | 50MHz | ― | -40～+125℃ |
1013cycles |
SOP-8 (150mil) | Tube | ES available | |
| Buy | MB85RS256TYAPNF-GSBCERE1 | Automotive Grade AEC-Q100 compliant | SPI | 256Kbit | 1.8V | 3.6V | 50MHz | ― | -40～+125℃ |
1013cycles |
SOP-8 (150mil) | Embossed taping | ES available | ||||
| Buy | MB85RS256TYAPN-GS-AWE1 | Automotive Grade AEC-Q100 compliant | SPI | 256Kbit | 1.8V | 3.6V | 50MHz | ― | -40～+125℃ |
1013cycles |
DFN-8 (5mmx6mm) | Tray | ES available | ||||
| Buy | MB85RS256TYAPN-GS-AWEWE1 | Automotive Grade AEC-Q100 compliant | SPI | 256Kbit | 1.8V | 3.6V | 50MHz | ― | -40～+125℃ |
1013cycles |
DFN-8 (5mmx6mm) | Embossed taping | ES available | ||||
| Buy | MB85RS256TYAPNF-G-BCE1 | Industrial Grade | SPI | 256Kbit | 1.8V | 3.6V | 50MHz | ― | -40～+125℃ |
1013cycles |
SOP-8 (150mil) | Tube | ES available | ||||
| Buy | MB85RS256TYAPNF-G-BCERE1 | Industrial Grade | SPI | 256Kbit | 1.8V | 3.6V | 50MHz | ― | -40～+125℃ |
1013cycles |
SOP-8 (150mil) | Embossed taping | ES available | ||||
| Buy | MB85RS256TYAPN-G-AWE1 | Industrial Grade | SPI | 256Kbit | 1.8V | 3.6V | 50MHz | ― | -40～+125℃ |
1013cycles |
DFN-8 (5mmx6mm) | Tray | ES available | ||||
| Buy | MB85RS256TYAPN-G-AWEWE1 | Industrial Grade | SPI | 256Kbit | 1.8V | 3.6V | 50MHz | ― | -40～+125℃ |
1013cycles |
DFN-8 (5mmx6mm) | Embossed taping | ES available | ||||
| MB85RS256TY | Datasheet | Verilog | IBIS | Buy | MB85RS256TYPNF-GS-BCE1 | Automotive Grade AEC-Q100 compliant | SPI | 256Kbit | 1.8V | 3.6V | 40MHz | ― | -40～+125℃ |
1013cycles |
SOP-8 (150mil) | Tube | In mass production |
| Buy | MB85RS256TYPNF-GS-BCERE1 | Automotive Grade AEC-Q100 compliant | SPI | 256Kbit | 1.8V | 3.6V | 40MHz | ― | -40～+125℃ |
1013cycles |
SOP-8 (150mil) | Embossed taping | In mass production | ||||
| Buy | MB85RS256TYPNF-GS-AWE2 | Automotive Grade AEC-Q100 compliant | SPI | 256Kbit | 1.8V | 3.6V | 40MHz | ― | -40～+125℃ |
1013cycles |
SOP-8 (150mil) | Tube | In mass production | ||||
| Buy | MB85RS256TYPNF-GS-AWERE2 | Automotive Grade AEC-Q100 compliant | SPI | 256Kbit | 1.8V | 3.6V | 40MHz | ― | -40～+125℃ |
1013cycles |
SOP-8 (150mil) | Embossed taping | In mass production | ||||
| Buy | MB85RS256TYPNF-G-BCE1 | Industrial Grade | SPI | 256Kbit | 1.8V | 3.6V | 33MHz | ― | -40～+125℃ |
1013cycles |
SOP-8 (150mil) | Tube | In mass production | ||||
| Buy | MB85RS256TYPNF-G-BCERE1 | Industrial Grade | SPI | 256Kbit | 1.8V | 3.6V | 33MHz | ― | -40～+125℃ |
1013cycles |
SOP-8 (150mil) | Embossed taping | In mass production | ||||
| MB85RS256LYA | Datasheet | IBIS | Buy | MB85RS256LYAPNF-GS-BCE1 | Automotive Grade AEC-Q100 compliant | SPI | 256Kbit | 1.7V | 1.95V | 50MHz | ― | -40～+125℃ |
1013cycles |
SOP-8 (150mil) | Tube | ES available | |
| Buy | MB85RS256LYAPNF-GSBCERE1 | Automotive Grade AEC-Q100 compliant | SPI | 256Kbit | 1.7V | 1.95V | 50MHz | ― | -40～+125℃ |
1013cycles |
SOP-8 (150mil) | Embossed taping | ES available | ||||
| Buy | MB85RS256LYAPN-GS-AWE1 | Automotive Grade AEC-Q100 compliant | SPI | 256Kbit | 1.7V | 1.95V | 50MHz | ― | -40～+125℃ |
1013cycles |
DFN-8 (5mmx6mm) | Tray | ES available | ||||
| Buy | MB85RS256LYAPN-GS-AWEWE1 | Automotive Grade AEC-Q100 compliant | SPI | 256Kbit | 1.7V | 1.95V | 50MHz | ― | -40～+125℃ |
1013cycles |
DFN-8 (5mmx6mm) | Embossed taping | ES available | ||||
| Buy | MB85RS256LYAPNF-G-BCE1 | Industrial Grade | SPI | 256Kbit | 1.7V | 1.95V | 50MHz | ― | -40～+125℃ |
1013cycles |
SOP-8 (150mil) | Tube | ES available | ||||
| Buy | MB85RS256LYAPNF-G-BCERE1 | Industrial Grade | SPI | 256Kbit | 1.7V | 1.95V | 50MHz | ― | -40～+125℃ |
1013cycles |
SOP-8 (150mil) | Embossed taping | ES available | ||||
| Buy | MB85RS256LYAPN-G-AWE1 | Industrial Grade | SPI | 256Kbit | 1.7V | 1.95V | 50MHz | ― | -40～+125℃ |
1013cycles |
DFN-8 (5mmx6mm) | Tray | ES available | ||||
| Buy | MB85RS256LYAPN-G-AWEWE1 | Industrial Grade | SPI | 256Kbit | 1.7V | 1.95V | 50MHz | ― | -40～+125℃ |
1013cycles |
DFN-8 (5mmx6mm) | Embossed taping | ES available | ||||
| MB85RS256B | Datasheet | Verilog | IBIS | Buy | MB85RS256BPNF-G-JNE1 | Industrial Grade | SPI | 256Kbit | 2.7V | 3.6V | 33MHz | ― | -40～+85℃ |
1012cycles |
SOP-8 (150mil) | Tube | NRND |
| Buy | MB85RS256BPNF-G-JNERE1 | Industrial Grade | SPI | 256Kbit | 2.7V | 3.6V | 33MHz | ― | -40～+85℃ |
1012cycles |
SOP-8 (150mil) | Embossed taping | NRND | ||||
| Buy | MB85RS256BPNF-G-AME2 | Industrial Grade | SPI | 256Kbit | 2.7V | 3.6V | 33MHz | ― | -40～+85℃ |
1012cycles |
SOP-8 (150mil) | Tray | In mass production | ||||
| Buy | MB85RS256BPNF-G-AMERE2 | Industrial Grade | SPI | 256Kbit | 2.7V | 3.6V | 33MHz | ― | -40～+85℃ |
1012cycles |
SOP-8 (150mil) | Embossed taping | In mass production | ||||
| MB85RS128TY | Datasheet | Verilog | IBIS | Buy | MB85RS128TYPNF-GS-BCE1 | Automotive Grade AEC-Q100 compliant | SPI | 128Kbit | 1.8V | 3.6V | 40MHz | ― | -40～+125℃ |
1013cycles |
SOP-8 (150mil) | Tube | In mass production |
| Buy | MB85RS128TYPNF-GS-BCERE1 | Automotive Grade AEC-Q100 compliant | SPI | 128Kbit | 1.8V | 3.6V | 40MHz | ― | -40～+125℃ |
1013cycles |
SOP-8 (150mil) | Embossed taping | In mass production | ||||
| Buy | MB85RS128TYPNF-G-BCE1 | Industrial Grade | SPI | 128Kbit | 1.8V | 3.6V | 33MHz | ― | -40～+125℃ |
1013cycles |
SOP-8 (150mil) | Tube | In mass production | ||||
| Buy | MB85RS128TYPNF-G-BCERE1 | Industrial Grade | SPI | 128Kbit | 1.8V | 3.6V | 33MHz | ― | -40～+125℃ |
1013cycles |
SOP-8 (150mil) | Embossed taping | In mass production | ||||
| MB85RS128B | Datasheet | Verilog | IBIS | Buy | MB85RS128BPNF-G-JNE1 | Industrial Grade | SPI | 128Kbit | 2.7V | 3.6V | 33MHz | ― | -40～+85℃ |
1012cycles |
SOP-8 (150mil) | Tube | In mass production |
| Buy | MB85RS128BPNF-G-JNERE1 | Industrial Grade | SPI | 128Kbit | 2.7V | 3.6V | 33MHz | ― | -40～+85℃ |
1012cycles |
SOP-8 (150mil) | Embossed taping | In mass production | ||||
| Buy | MB85RS128BPNF-G-AME2 | Industrial Grade | SPI | 128Kbit | 2.7V | 3.6V | 33MHz | ― | -40～+85℃ |
1012cycles |
SOP-8 (150mil) | Tube | In mass production | ||||
| Buy | MB85RS128BPNF-G-AMERE2 | Industrial Grade | SPI | 128Kbit | 2.7V | 3.6V | 33MHz | ― | -40～+85℃ |
1012cycles |
SOP-8 (150mil) | Embossed taping | In mass production | ||||
| MB85RS64VY | Datasheet | Verilog | IBIS | Buy | MB85RS64VYPNF-GS-BCE1 | Automotive Grade AEC-Q100 compliant | SPI | 64Kbit | 2.7V | 5.5V | 33MHz | ― | -40～+125℃ |
1013cycles |
SOP-8 (150mil) | Tube | In mass production |
| Buy | MB85RS64VYPNF-GS-BCERE1 | Automotive Grade AEC-Q100 compliant | SPI | 64Kbit | 2.7V | 5.5V | 33MHz | ― | -40～+125℃ |
1013cycles |
SOP-8 (150mil) | Embossed taping | In mass production | ||||
| Buy | MB85RS64VYPNF-G-BCE1 | Industrial Grade | SPI | 64Kbit | 3.0V | 5.5V | 20MHz | ― | -40～+85℃ |
1012cycles |
SOP-8 (150mil) | Tube | In mass production | ||||
| Buy | MB85RS64VYPNF-G-BCERE1 | Industrial Grade | SPI | 64Kbit | 2.7V | 5.5V | 33MHz | ― | -40～+125℃ |
1013cycles |
SOP-8 (150mil) | Embossed taping | In mass production | ||||
| Buy | MB85RS64VYPN-G-AMEWE1 | Industrial Grade | SPI | 64Kbit | 2.7V | 5.5V | 33MHz | ― | -40～+125℃ |
1013cycles |
SON-8 (2mmx3mm) | Embossed taping | In mass production | ||||
| MB85RS64T | Datasheet | Verilog | IBIS | Buy | MB85RS64TPNF-G-JNE2 | Industrial Grade | SPI | 64Kbit | 1.7V | 3.6V | 10MHz | ― | -40～+85℃ |
1013cycles |
SOP-8 (150mil) | Tube | In mass production |
| Buy | MB85RS64TPNF-G-JNERE2 | Industrial Grade | SPI | 64Kbit | 1.7V | 3.6V | 10MHz | ― | -40～+85℃ |
1013cycles |
SOP-8 (150mil) | Embossed taping | In mass production | ||||
| Buy | MB85RS64TPNF-G-AME2 | Industrial Grade | SPI | 64Kbit | 1.7V | 3.6V | 10MHz | ― | -40～+85℃ |
1013cycles |
SOP-8 (150mil) | Tray | Available CY2025 | ||||
| Buy | MB85RS64TPNF-G-AMERE2 | Industrial Grade | SPI | 64Kbit | 1.7V | 3.6V | 10MHz | ― | -40～+85℃ |
1013cycles |
SOP-8 (150mil) | Embossed taping | Available CY2025 | ||||
| Buy | MB85RS64TPN-G-AMEWE1 | Industrial Grade | SPI | 64Kbit | 1.8V | 3.6V | 10MHz | ― | -40～+85℃ |
1013cycles |
SON-8 (2mmx3mm) | Embossed taping | In mass production | ||||
| MB85RS64 | Datasheet | Verilog | IBIS | Buy | MB85RS64PNF-G-JNE1 | Industrial Grade | SPI | 64Kbit | 2.7V | 3.6V | 20MHz | ― | -40～+85℃ |
1012cycles |
SOP-8 (150mil) | Tube | NRND |
| Buy | MB85RS64PNF-G-JNERE1 | Industrial Grade | SPI | 64Kbit | 2.7V | 3.6V | 20MHz | ― | -40～+85℃ |
1012cycles |
SOP-8 (150mil) | Embossed taping | NRND | ||||
| Buy | MB85RS64PNF-G-AME2 | Industrial Grade | SPI | 64Kbit | 2.7V | 3.6V | 20MHz | ― | -40～+85℃ |
1012cycles |
SOP-8 (150mil) | Tray | In mass production | ||||
| Buy | MB85RS64PNF-G-AMERE2 | Industrial Grade | SPI | 64Kbit | 2.7V | 3.6V | 20MHz | ― | -40～+85℃ |
1012cycles |
SOP-8 (150mil) | Embossed taping | In mass production | ||||
| MB85RS16 | Datasheet | Verilog | IBIS | Buy | MB85RS16PNF-G-JNE1 | Industrial Grade | SPI | 16Kbit | 2.7V | 3.6V | 20MHz | ― | -40～+85℃ |
1012cycles |
SOP-8 (150mil) | Tube | In mass production |
| Buy | MB85RS16PNF-G-JNERE1 | Industrial Grade | SPI | 16Kbit | 2.7V | 3.6V | 20MHz | ― | -40～+85℃ |
1012cycles |
SOP-8 (150mil) | Embossed taping | In mass production | ||||
| MB85RS16N | Datasheet | Verilog | IBIS | Buy | MB85RS16NPNF-G-JNE1 | Industrial Grade | SPI | 16Kbit | 2.7V | 3.6V | 20MHz | ― | -40～+95℃ |
1012cycles |
SOP-8 (150mil) | Tube | NRND |
| Buy | MB85RS16NPNF-G-JNERE1 | Industrial Grade | SPI | 16Kbit | 2.7V | 3.6V | 20MHz | ― | -40～+95℃ |
1012cycles |
SOP-8 (150mil) | Embossed taping | NRND | ||||
| Buy | MB85RS16NPNF-G-AME2 | Industrial Grade | SPI | 16Kbit | 2.7V | 3.6V | 20MHz | ― | -40～+95℃ |
1012cycles |
SOP-8 (150mil) | Tray | In mass production | ||||
| Buy | MB85RS16NPNF-G-AMERE2 | Industrial Grade | SPI | 16Kbit | 2.7V | 3.6V | 20MHz | ― | -40～+95℃ |
1012cycles |
SOP-8 (150mil) | Embossed taping | In mass production | ||||
| Buy | MB85RS16NPN-G-AMEWE1 | Industrial Grade | SPI | 16Kbit | 2.7V | 3.6V | 20MHz | ― | -40～+95℃ |
1012cycles |
SON-8 (2mmx3mm) | Embossed taping | In mass production | ||||
| MB85RD16LX | Datasheet | Verilog | IBIS | - | MB85RD16LXPN-G-AMEWE1 | Industrial Grade | Dual SPI | 16Kbit | 1.65V | 1.95V | 15MHz | ― | -40～+125℃ |
1013cycles |
SON-8 (2mmx3mm) | Embossed taping | In mass production |
| MS85RC1MTY | Datasheet | MS85RC1MTYPN-GS-AWE1 | Automotive Grade AEC-Q100 compliant | I2C | 1Mbit | 1.8V | 3.6V | 3.4MHz | ― | -40～+125℃ |
1013cycles |
SOP-8 (150mil) | Tube | ES CY2025 | |||
| MS85RC1MTYPN-GS-AWEWE1 | Automotive Grade AEC-Q100 compliant | I2C | 1Mbit | 1.8V | 3.6V | 3.4MHz | ― | -40～+125℃ |
1013cycles |
SOP-8 (150mil) | Embossed taping | ES CY2025 | |||||
| MS85RC1MTYPNF-GS-BDE1 | Automotive Grade AEC-Q100 compliant | I2C | 1Mbit | 1.8V | 3.6V | 3.4MHz | ― | -40～+125℃ |
1013cycles |
DFN-8 (5mmx6mm) | Tray | ES available | |||||
| MS85RC1MTYPNF-GS-BDERE1 | Automotive Grade AEC-Q100 compliant | I2C | 1Mbit | 1.8V | 3.6V | 3.4MHz | ― | -40～+125℃ |
1013cycles |
DFN-8 (5mmx6mm) | Embossed taping | ES available | |||||
| MS85RC1MTYPN-G-AWE1 | Industrial Grade | I2C | 1Mbit | 1.8V | 3.6V | 3.4MHz | ― | -40～+125℃ |
1014cycles |
SOP-8 (150mil) | Tube | ES CY2025 | |||||
| MS85RC1MTYPN-G-AWEWE1 | Industrial Grade | I2C | 1Mbit | 1.8V | 3.6V | 3.4MHz | ― | -40～+125℃ |
1014cycles |
SOP-8 (150mil) | Embossed taping | ES CY2025 | |||||
| MS85RC1MTYPNF-G-BDE1 | Industrial Grade | I2C | 1Mbit | 1.8V | 3.6V | 3.4MHz | ― | -40～+125℃ |
1014cycles |
DFN-8 (5mmx6mm) | Tray | ES available | |||||
| MS85RC1MTYPNF-G-BDERE1 | Industrial Grade | I2C | 1Mbit | 1.8V | 3.6V | 3.4MHz | ― | -40～+125℃ |
1014cycles |
DFN-8 (5mmx6mm) | Embossed taping | ES available | |||||
| MB85RC1MT | Datasheet | Verilog | IBIS | Buy | MB85RC1MTPNF-G-JNE1 | Industrial Grade | I2C | 1Mbit | 1.8V | 3.6V | 3.4MHz | ― | -40～+85℃ |
1013cycles |
SOP-8 (150mil) | Tube | In mass production |
| Buy | MB85RC1MTPNF-G-JNERE1 | Industrial Grade | I2C | 1Mbit | 1.8V | 3.6V | 3.4MHz | ― | -40～+85℃ |
1013cycles |
SOP-8 (150mil) | Embossed taping | In mass production | ||||
| Buy | MB85RC1MTPNF-G-AME2 | Industrial Grade | I2C | 1Mbit | 1.8V | 3.6V | 3.4MHz | ― | -40～+85℃ |
1013cycles |
SOP-8 (150mil) | Tray | In mass production | ||||
| Buy | MB85RC1MTPNF-G-AMERE2 | Industrial Grade | I2C | 1Mbit | 1.8V | 3.6V | 3.4MHz | ― | -40～+85℃ |
1013cycles |
SOP-8 (150mil) | Embossed taping | In mass production | ||||
| MB85RC512TY | Datasheet | IBIS | Buy | MB85RC512TYPNF-GS-BCE1 | Automotive Grade AEC-Q100 compliant | I2C | 512Kbit | 1.8V | 3.6V | 3.4MHz | ― | -40～+125℃ |
1013cycles |
SOP-8 (150mil) | Tube | ES available | |
| Buy | MB85RC512TYPNF-GS-BCERE1 | Automotive Grade AEC-Q100 compliant | I2C | 512Kbit | 1.8V | 3.6V | 3.4MHz | ― | -40～+125℃ |
1013cycles |
SOP-8 (150mil) | Embossed taping | ES available | ||||
| Buy | MB85RC512TYPN-GS-AWE1 | Automotive Grade AEC-Q100 compliant | I2C | 512Kbit | 1.8V | 3.6V | 3.4MHz | ― | -40～+125℃ |
1013cycles |
DFN-8 (5mmx6mm) | Tray | ES available | ||||
| Buy | MB85RC512TYPN-GS-AWEWE1 | Automotive Grade AEC-Q100 compliant | I2C | 512Kbit | 1.8V | 3.6V | 3.4MHz | ― | -40～+125℃ |
1013cycles |
DFN-8 (5mmx6mm) | Embossed taping | ES available | ||||
| Buy | MB85RC512TYPNF-G-BCE1 | Industrial Grade | I2C | 512Kbit | 1.8V | 3.6V | 3.4MHz | ― | -40～+125℃ |
1013cycles |
SOP-8 (150mil) | Tube | ES available | ||||
| Buy | MB85RC512TYPNF-G-BCERE1 | Industrial Grade | I2C | 512Kbit | 1.8V | 3.6V | 3.4MHz | ― | -40～+125℃ |
1013cycles |
SOP-8 (150mil) | Embossed taping | ES available | ||||
| Buy | MB85RC512TYPN-G-AWE1 | Industrial Grade | I2C | 512Kbit | 1.8V | 3.6V | 3.4MHz | ― | -40～+125℃ |
1013cycles |
DFN-8 (5mmx6mm) | Tray | ES available | ||||
| Buy | MB85RC512TYPN-G-AWEWE1 | Industrial Grade | I2C | 512Kbit | 1.8V | 3.6V | 3.4MHz | ― | -40～+125℃ |
1013cycles |
DFN-8 (5mmx6mm) | Embossed taping | ES available | ||||
| MB85RC512LY | Datasheet | In preparation | Buy | MB85RC512LYPNF-GS-BCE1 | Automotive Grade AEC-Q100 compliant | I2C | 512Kbit | 1.7V | 1.95V | 3.4MHz | ― | -40～+125℃ |
1013cycles |
SOP-8 (150mil) | Tube | ES available | |
| Buy | MB85RC512LYPNF-GS-BCERE1 | Automotive Grade AEC-Q100 compliant | I2C | 512Kbit | 1.7V | 1.95V | 3.4MHz | ― | -40～+125℃ |
1013cycles |
SOP-8 (150mil) | Embossed taping | ES available | ||||
| Buy | MB85RC512LYPN-GS-AWE1 | Automotive Grade AEC-Q100 compliant | I2C | 512Kbit | 1.7V | 1.95V | 3.4MHz | ― | -40～+125℃ |
1013cycles |
DFN-8 (5mmx6mm) | Tray | ES available | ||||
| Buy | MB85RC512LYPN-GS-AWEWE1 | Automotive Grade AEC-Q100 compliant | I2C | 512Kbit | 1.7V | 1.95V | 3.4MHz | ― | -40～+125℃ |
1013cycles |
DFN-8 (5mmx6mm) | Embossed taping | ES available | ||||
| Buy | MB85RC512LYPNF-G-BCE1 | Industrial Grade | I2C | 512Kbit | 1.7V | 1.95V | 3.4MHz | ― | -40～+125℃ |
1013cycles |
SOP-8 (150mil) | Tube | ES available | ||||
| Buy | MB85RC512LYPNF-G-BCERE1 | Industrial Grade | I2C | 512Kbit | 1.7V | 1.95V | 3.4MHz | ― | -40～+125℃ |
1013cycles |
SOP-8 (150mil) | Embossed taping | ES available | ||||
| Buy | MB85RC512LYPN-G-AWE1 | Industrial Grade | I2C | 512Kbit | 1.7V | 1.95V | 3.4MHz | ― | -40～+125℃ |
1013cycles |
DFN-8 (5mmx6mm) | Tray | ES available | ||||
| Buy | MB85RC512LYPN-G-AWEWE1 | Industrial Grade | I2C | 512Kbit | 1.7V | 1.95V | 3.4MHz | ― | -40～+125℃ |
1013cycles |
DFN-8 (5mmx6mm) | Embossed taping | ES available | ||||
| MB85RC512T | Datasheet | Verilog | IBIS | Buy | MB85RC512TPNF-G-JNE1 | Industrial Grade | I2C | 512Kbit | 1.7V | 3.6V | 3.4MHz | ― | -40～+85℃ |
1013cycles |
SOP-8 (150mil) | Tube | NRND |
| Buy | MB85RC512TPNF-G-JNERE1 | Industrial Grade | I2C | 512Kbit | 1.7V | 3.6V | 3.4MHz | ― | -40～+85℃ |
1013cycles |
SOP-8 (150mil) | Embossed taping | NRND | ||||
| Buy | MB85RC512TPNF-G-AME2 | Industrial Grade | I2C | 512Kbit | 1.7V | 3.6V | 3.4MHz | ― | -40～+85℃ |
1013cycles |
SOP-8 (150mil) | Tray | In mass production | ||||
| Buy | MB85RC512TPNF-G-AMERE2 | Industrial Grade | I2C | 512Kbit | 1.7V | 3.6V | 3.4MHz | ― | -40～+85℃ |
1013cycles |
SOP-8 (150mil) | Embossed taping | In mass production | ||||
| MB85RC256TY | Datasheet | IBIS | Buy | MB85RC256TYPNF-GS-BCE1 | Automotive Grade AEC-Q100 compliant | I2C | 256Kbit | 1.8V | 3.6V | 3.4MHz | ― | -40～+125℃ |
1013cycles |
SOP-8 (150mil) | Tube | ES available | |
| Buy | MB85RC256TYPNF-GS-BCERE1 | Automotive Grade AEC-Q100 compliant | I2C | 256Kbit | 1.8V | 3.6V | 3.4MHz | ― | -40～+125℃ |
1013cycles |
SOP-8 (150mil) | Embossed taping | ES available | ||||
| Buy | MB85RC256TYPN-GS-AWE1 | Automotive Grade AEC-Q100 compliant | I2C | 256Kbit | 1.8V | 3.6V | 3.4MHz | ― | -40～+125℃ |
1013cycles |
DFN-8 (5mmx6mm) | Tray | ES available | ||||
| Buy | MB85RC256TYPN-GS-AWEWE1 | Automotive Grade AEC-Q100 compliant | I2C | 256Kbit | 1.8V | 3.6V | 3.4MHz | ― | -40～+125℃ |
1013cycles |
DFN-8 (5mmx6mm) | Embossed taping | ES available | ||||
| Buy | MB85RC256TYPNF-G-BCE1 | Industrial Grade | I2C | 256Kbit | 1.8V | 3.6V | 3.4MHz | ― | -40～+125℃ |
1013cycles |
SOP-8 (150mil) | Tube | ES available | ||||
| Buy | MB85RC256TYPNF-G-BCERE1 | Industrial Grade | I2C | 256Kbit | 1.8V | 3.6V | 3.4MHz | ― | -40～+125℃ |
1013cycles |
SOP-8 (150mil) | Embossed taping | ES available | ||||
| Buy | MB85RC256TYPN-G-AWE1 | Industrial Grade | I2C | 256Kbit | 1.8V | 3.6V | 3.4MHz | ― | -40～+125℃ |
1013cycles |
DFN-8 (5mmx6mm) | Tray | ES available | ||||
| Buy | MB85RC256TYPN-G-AWEWE1 | Industrial Grade | I2C | 256Kbit | 1.8V | 3.6V | 3.4MHz | ― | -40～+125℃ |
1013cycles |
DFN-8 (5mmx6mm) | Embossed taping | ES available | ||||
| MB85RC256LY | Datasheet | IBIS | Buy | MB85RC256LYPNF-GS-BCE1 | Automotive Grade AEC-Q100 compliant | I2C | 256Kbit | 1.7V | 1.95V | 3.4MHz | ― | -40～+125℃ |
1013cycles |
SOP-8 (150mil) | Tube | ES available | |
| Buy | MB85RC256LYPNF-GS-BCERE1 | Automotive Grade AEC-Q100 compliant | I2C | 256Kbit | 1.7V | 1.95V | 3.4MHz | ― | -40～+125℃ |
1013cycles |
SOP-8 (150mil) | Embossed taping | ES available | ||||
| Buy | MB85RC256LYPN-GS-AWE1 | Automotive Grade AEC-Q100 compliant | I2C | 256Kbit | 1.7V | 1.95V | 3.4MHz | ― | -40～+125℃ |
1013cycles |
DFN-8 (5mmx6mm) | Tray | ES available | ||||
| Buy | MB85RC256LYPN-GS-AWEWE1 | Automotive Grade AEC-Q100 compliant | I2C | 256Kbit | 1.7V | 1.95V | 3.4MHz | ― | -40～+125℃ |
1013cycles |
DFN-8 (5mmx6mm) | Embossed taping | ES available | ||||
| Buy | MB85RC256LYPNF-G-BCE1 | Industrial Grade | I2C | 256Kbit | 1.7V | 1.95V | 3.4MHz | ― | -40～+125℃ |
1013cycles |
SOP-8 (150mil) | Tube | ES available | ||||
| Buy | MB85RC256LYPNF-G-BCERE1 | Industrial Grade | I2C | 256Kbit | 1.7V | 1.95V | 3.4MHz | ― | -40～+125℃ |
1013cycles |
SOP-8 (150mil) | Embossed taping | ES available | ||||
| Buy | MB85RC256LYPN-G-AWE1 | Industrial Grade | I2C | 256Kbit | 1.7V | 1.95V | 3.4MHz | ― | -40～+125℃ |
1013cycles |
DFN-8 (5mmx6mm) | Tray | ES available | ||||
| Buy | MB85RC256LYPN-G-AWEWE1 | Industrial Grade | I2C | 256Kbit | 1.7V | 1.95V | 3.4MHz | ― | -40～+125℃ |
1013cycles |
DFN-8 (5mmx6mm) | Embossed taping | ES available | ||||
| MB85RC256V | Datasheet | Verilog | IBIS | Buy | MB85RC256VPNF-G-JNE1 | Industrial Grade | I2C | 256Kbit | 2.7V | 5.5V | 1MHz | ― | -40～+85℃ |
1012cycles |
SOP-8 (150mil) | Tube | NRND |
| Buy | MB85RC256VPNF-G-JNERE1 | Industrial Grade | I2C | 256Kbit | 2.7V | 5.5V | 1MHz | ― | -40～+85℃ |
1012cycles |
SOP-8 (150mil) | Embossed taping | NRND | ||||
| Buy | MB85RC256VPNF-G-AME2 | Industrial Grade | I2C | 256Kbit | 2.7V | 5.5V | 1MHz | ― | -40～+85℃ |
1012cycles |
SOP-8 (150mil) | Tray | In mass production | ||||
| Buy | MB85RC256VPNF-G-AMERE2 | Industrial Grade | I2C | 256Kbit | 2.7V | 5.5V | 1MHz | ― | -40～+85℃ |
1012cycles |
SOP-8 (150mil) | Embossed taping | In mass production | ||||
| Buy | MB85RC256VPF-G-BCE1 | Industrial Grade | I2C | 256Kbit | 2.7V | 5.5V | 1MHz | ― | -40～+85℃ |
1012cycles |
SOP-8 (208mil) | Tube | In mass production | ||||
| Buy | MB85RC256VPF-G-BCERE1 | Industrial Grade | I2C | 256Kbit | 2.7V | 5.5V | 1MHz | ― | -40～+85℃ |
1012cycles |
SOP-8 (208mil) | Embossed taping | In mass production | ||||
| MB85RC256VN | Datasheet | Verilog | IBIS | Buy | MB85RC256VNPNF-G-AME2 | Industrial Grade | I2C | 256Kbit | 2.7V | 5.5V | 1MHz | ― | -40～+95℃ |
1012cycles |
SOP-8 (150mil) | Tray | In mass production |
| Buy | MB85RC256VNPNF-G-AMERE2 | Industrial Grade | I2C | 256Kbit | 2.7V | 5.5V | 1MHz | ― | -40～+95℃ |
1012cycles |
SOP-8 (150mil) | Embossed taping | In mass production | ||||
| MB85RC128A | Datasheet | Verilog | IBIS | Buy | MB85RC128APNF-G-JNE1 | Industrial Grade | I2C | 128Kbit | 2.7V | 3.6V | 1MHz | ― | -40～+85℃ |
1012cycles |
SOP-8 (150mil) | Tube | In mass production |
| Buy | MB85RC128APNF-G-JNERE1 | Industrial Grade | I2C | 128Kbit | 2.7V | 3.6V | 1MHz | ― | -40～+85℃ |
1012cycles |
SOP-8 (150mil) | Embossed taping | In mass production | ||||
| Buy | MB85RC128APNF-G-AME2 | Industrial Grade | I2C | 128Kbit | 2.7V | 3.6V | 1MHz | ― | -40～+85℃ |
1012cycles |
SOP-8 (150mil) | Tray | Available CY2025 | ||||
| Buy | MB85RC128APNF-G-AMERE2 | Industrial Grade | I2C | 128Kbit | 2.7V | 3.6V | 1MHz | ― | -40～+85℃ |
1012cycles |
SOP-8 (150mil) | Embossed taping | Available CY2025 | ||||
| MB85RC64TA | Datasheet | Verilog | Buy | MB85RC64TAPNF-G-BDE1 | Industrial Grade | I2C | 64Kbit | 1.8V | 3.6V | 3.4MHz | ― | -40～+85℃ |
1013cycles |
SOP-8 (150mil) | Tube | In mass production | |
| Buy | MB85RC64TAPNF-G-BDERE1 | Industrial Grade | I2C | 64Kbit | 1.8V | 3.6V | 3.4MHz | ― | -40～+85℃ |
1013cycles |
SOP-8 (150mil) | Embossed taping | In mass production | ||||
| Buy | MB85RC64TAPNF-G-AWE2 | Industrial Grade | I2C | 64Kbit | 1.8V | 3.6V | 3.4MHz | ― | -40～+85℃ |
1013cycles |
SOP-8 (150mil) | Tube | In mass production | ||||
| Buy | MB85RC64TAPNF-G-AWERE2 | Industrial Grade | I2C | 64Kbit | 1.8V | 3.6V | 3.4MHz | ― | -40～+85℃ |
1013cycles |
SOP-8 (150mil) | Embossed taping | In mass production | ||||
| Buy | MB85RC64TAPN-G-AMEWE1 | Industrial Grade | I2C | 64Kbit | 1.8V | 3.6V | 3.4MHz | ― | -40～+85℃ |
1013cycles |
SON-8 (2mmx3mm) | Embossed taping | In mass production | ||||
| MB85RC64A | Datasheet | Verilog | IBIS | Buy | MB85RC64APNF-G-JNE1 | Industrial Grade | I2C | 64Kbit | 2.7V | 3.6V | 1MHz | ― | -40～+85℃ |
1012cycles |
SOP-8 (150mil) | Tube | NRND |
| Buy | MB85RC64APNF-G-JNERE1 | Industrial Grade | I2C | 64Kbit | 2.7V | 3.6V | 1MHz | ― | -40～+85℃ |
1012cycles |
SOP-8 (150mil) | Embossed taping | NRND | ||||
| Buy | MB85RC64APNF-G-AME2 | Industrial Grade | I2C | 64Kbit | 2.7V | 3.6V | 1MHz | ― | -40～+85℃ |
1012cycles |
SOP-8 (150mil) | Tray | In mass production | ||||
| Buy | MB85RC64APNF-G-AMERE2 | Industrial Grade | I2C | 64Kbit | 2.7V | 3.6V | 1MHz | ― | -40～+85℃ |
1012cycles |
SOP-8 (150mil) | Embossed taping | In mass production | ||||
| MB85RC64V | Datasheet | Verilog | IBIS | Buy | MB85RC64VPNF-G-JNE1 | Industrial Grade | I2C | 64Kbit | 3.0V | 5.5V | 1MHz | ― | -40～+85℃ |
1012cycles |
SOP-8 (150mil) | Tube | NRND |
| Buy | MB85RC64VPNF-G-JNERE1 | Industrial Grade | I2C | 64Kbit | 3.0V | 5.5V | 1MHz | ― | -40～+85℃ |
1012cycles |
SOP-8 (150mil) | Embossed taping | NRND | ||||
| Buy | MB85RC64VPNF-G-AME2 | Industrial Grade | I2C | 64Kbit | 3.0V | 5.5V | 1MHz | ― | -40～+85℃ |
1012cycles |
SOP-8 (150mil) | Tray | In mass production | ||||
| Buy | MB85RC64VPNF-G-AMERE2 | Industrial Grade | I2C | 64Kbit | 3.0V | 5.5V | 1MHz | ― | -40～+85℃ |
1012cycles |
SOP-8 (150mil) | Embossed taping | In mass production | ||||
| MB85RC16 | Datasheet | Verilog | IBIS | Buy | MB85RC16PNF-G-JNE1 | Industrial Grade | I2C | 16Kbit | 2.7V | 3.6V | 1MHz | ― | -40～+85℃ |
1012cycles |
SOP-8 (150mil) | Tube | In mass production |
| Buy | MB85RC16PNF-G-JNERE1 | Industrial Grade | I2C | 16Kbit | 2.7V | 3.6V | 1MHz | ― | -40～+85℃ |
1012cycles |
SOP-8 (150mil) | Embossed taping | In mass production | ||||
| Buy | MB85RC16PN-G-AMERE1 | Industrial Grade | I2C | 16Kbit | 2.7V | 3.6V | 1MHz | ― | -40～+85℃ |
1012cycles |
SON-8 (2mmx3mm) | Embossed taping | In mass production | ||||
| MB85RC16V | Datasheet | Verilog | IBIS | Buy | MB85RC16VPNF-G-JNN1E1 | Industrial Grade | I2C | 16Kbit | 3.0V | 5.5V | 1MHz | ― | -40～+85℃ |
1012cycles |
SOP-8 (150mil) | Tube | NRND |
| Buy | MB85RC16VPNF-G-JNN1ERE1 | Industrial Grade | I2C | 16Kbit | 3.0V | 5.5V | 1MHz | ― | -40～+85℃ |
1012cycles |
SOP-8 (150mil) | Embossed taping | NRND | ||||
| Buy | MB85RC16VPNF-G-AWE2 | Industrial Grade | I2C | 16Kbit | 3.0V | 5.5V | 1MHz | ― | -40～+85℃ |
1012cycles |
SOP-8 (150mil) | Tube | In mass production | ||||
| Buy | MB85RC16VPNF-G-AWERE2 | Industrial Grade | I2C | 16Kbit | 3.0V | 5.5V | 1MHz | ― | -40～+85℃ |
1012cycles |
SOP-8 (150mil) | Embossed taping | In mass production | ||||
| Buy | MB85RC16VPNF-G-AME2 | Industrial Grade | I2C | 16Kbit | 3.0V | 5.5V | 1MHz | ― | -40～+85℃ |
1012cycles |
SOP-8 (150mil) | Tray | In mass production | ||||
| Buy | MB85RC16VPNF-G-AMERE2 | Industrial Grade | I2C | 16Kbit | 3.0V | 5.5V | 1MHz | ― | -40～+85℃ |
1012cycles |
SOP-8 (150mil) | Embossed taping | In mass production | ||||
| MB85RC04 | Datasheet | IBIS | Buy | MB85RC04PNF-G-JNE1 | Industrial Grade | I2C | 4Kbit | 2.7V | 3.6V | 400KHz | ― | -40～+85℃ |
1012cycles |
SOP-8 (150mil) | Tube | NRND | |
| Buy | MB85RC04PNF-G-JNERE1 | Industrial Grade | I2C | 4Kbit | 2.7V | 3.6V | 400KHz | ― | -40～+85℃ |
1012cycles |
SOP-8 (150mil) | Embossed taping | NRND | ||||
| Buy | MB85RC04PNF-G-AME2 | Industrial Grade | I2C | 4Kbit | 2.7V | 3.6V | 400KHz | ― | -40～+85℃ |
1012cycles |
SOP-8 (150mil) | Tray | In mass production | ||||
| Buy | MB85RC04PNF-G-AMERE2 | Industrial Grade | I2C | 4Kbit | 2.7V | 3.6V | 400KHz | ― | -40～+85℃ |
1012cycles |
SOP-8 (150mil) | Embossed taping | In mass production | ||||
| MB85RC04V | Datasheet | Verilog | IBIS | Buy | MB85RC04VPNF-G-JNE1 | Industrial Grade | I2C | 4Kbit | 3.0V | 5.5V | 1MHz | ― | -40～+85℃ |
1012cycles |
SOP-8 (150mil) | Tube | NRND |
| Buy | MB85RC04VPNF-G-JNERE1 | Industrial Grade | I2C | 4Kbit | 3.0V | 5.5V | 1MHz | ― | -40～+85℃ |
1012cycles |
SOP-8 (150mil) | Embossed taping | NRND | ||||
| Buy | MB85RC04VPNF-G-AME2 | Industrial Grade | I2C | 4Kbit | 3.0V | 5.5V | 1MHz | ― | -40～+85℃ |
1012cycles |
SOP-8 (150mil) | Tray | In mass production | ||||
| Buy | MB85RC04VPNF-G-AMERE2 | Industrial Grade | I2C | 4Kbit | 3.0V | 5.5V | 1MHz | ― | -40～+85℃ |
1012cycles |
SOP-8 (150mil) | Embossed taping | In mass production | ||||
| MB85R8M1TA | Datasheet | Verilog | IBIS | Buy | MB85R8M1TAFN-G-JAE2 | Industrial Grade | Parallel(×8) | 8Mbit | 1.8V | 3.6V | ― | 130ns | -40～+85℃ |
1014cycles |
TSOP-44 | Tray | In mass production |
| Buy | MB85R8M1TABGL-G-JAE1 | Industrial Grade | Parallel(×8) | 8Mbit | 1.8V | 3.6V | ― | 130ns | -40～+85℃ |
1014cycles |
FBGA-48 | Tray | In mass production | ||||
| MB85R8M2TA | Datasheet | Verilog | IBIS | Buy | MB85R8M2TAFN-G-JAE2 | Industrial Grade | Parallel(×16) | 8Mbit | 1.8V | 3.6V | ― | 130ns | -40～+85℃ |
1014cycles |
TSOP-44 | Tray | In mass production |
| Buy | MB85R8M2TABGL-G-JAE1 | Industrial Grade | Parallel(×16) | 8Mbit | 1.8V | 3.6V | ― | 130ns | -40～+85℃ |
1014cycles |
FBGA-48 | Tray | In mass production | ||||
| MS85R4M2TA | Datasheet | Buy | MS85R4M1TAFN-G-JAE2 | Industrial Grade | Parallel(×16) | 4Mbit | 1.8V | 3.6V | ― | 150ns | -40～+105℃ |
1014cycles |
TSOP-44 | Tray | ES available | ||
| MS85R4M1TA | Datasheet | Buy | MS85R4M2TAFN-G-JAE2 | Industrial Grade | Parallel(×8) | 4Mbit | 1.8V | 3.6V | ― | 150ns | -40～+105℃ |
1014cycles |
TSOP-44 | Tray | ES available | ||
| MB85R4M2T | Datasheet | Verilog | IBIS | - | MB85R4M2TFN-G-JAE2 | Industrial Grade | Parallel(×16) | 4Mbit | 1.8V | 3.6V | ― | 150ns | -40～+85℃ |
1013cycles |
TSOP-44 | Tray | In mass production |
| MB85R1001A | Datasheet | Verilog | IBIS | - | MB85R1001ANC-GE1 | Industrial Grade | Parallel(×8) | 1Mbit | 3.0V | 3.6V | ― | 150ns | -40～+85℃ |
1010cycles |
TSOP-48 | Tray | In mass production |
| MB85R1002A | Datasheet | IBIS | - | MB85R1002ANC-GE1 | Industrial Grade | Parallel(×16) | 1Mbit | 3.0V | 3.6V | ― | 150ns | -40～+85℃ |
1010cycles |
TSOP-48 | Tray | In mass production | |
| MB85R256F | Datasheet | IBIS | - | MB85R256FPFCN-G-BNDE1 | Industrial Grade | Parallel(×8) | 256Kbit | 2.7V | 3.6V | ― | 150ns | -40～+85℃ |
1012cycles |
TSOP-28 | Tray | In mass production |
